Cushman Hauler 1200X
July 24, 2023
Cushman Hauler 1200
The fuel-efficient 13.5 hp EFI gas engine, customizable bed, and practical dash design are ready to effortlessly transport tools and equipment needed for the toughest jobs. Attack each day with the power of the Hauler 1200 and give workday productivity a whole new meaning. Never back down from a challenge and never be outworked with the Hauler 1200.
- 13.5 – hp gas engine with closed-loop electronic fuel injection
- 1500 lb Towing Capacity
- 1200 lb Vehicle Load Capacity
| Frame | Welded Steel with DuraShield™ Powder Coat |
|---|---|
| Body & Finish | Injection-molded TPO |
| Available Colors | Black, Bright White, Flame Red, Forest Green, Metallic Charcoal, Orange, Patriot Blue, Safety Yellow |
| Overall Length | 119 in (302.3 cm) |
| Overall Width | 49.4 in (125.5 cm) |
| Overall Height | No Canopy: 47.3 in (120.1 cm), With Canopy: 70.5 in (179.1 cm) |
| Wheel Base | 76.8 in (195.1 cm) |
| Wheel Track | Front: 35 in (88.9 cm), Rear: 38.5 in (97.8 cm) |
| Ground Clearance | 3.5 in (8.9 cm) |
| Cargo Deck Capacity | 12-cu-ft (0.34 m3) |
| Cargo Deck Material | Roto-Molded Polyethylene |
| Power Source | 4-Cycle, 24.5 cu in (401cc) |
| Valve Train | Single Cylinder OHV |
| Horsepower (KW) | 13.5 hp (10.1 kW) |
| Electrical System | Starter/Generator – Solid State Regulator |
| Battery (Qty/Type) | One, 12-volt Maintenance Free |
| Key or Pedal Start | Pedal |
| Air Cleaner | Replaceable Dry Cartridge |
| Lubrication | Pressurized Oil System |
| Oil Filter | Spin-on |
| Cooling System | Air Cooled |
| Fuel Capacity | 6.65 Gallon (25 L) Tank |
| Drive Train | Continuously Variable Transmission (CVT) |
| Transaxle | Differential w/ Helical Gears |
| Gear Selection | Forward – Reverse |
| Rear Axle Ratio | 11.42:1 (Forward), 14.35:1 (Reverse) |
| Seating Capacity | 2 Person |
| Curb Weight | 980 lb (444.5 kg) |
| Vehicle Load Capacity | 1200 lb (544 kg) |
| Towing Capacity | 1500 lb (680.4 kg) Max Load |
| Bed Load Capacity | 800 lb (362.9 kg) |
| Outside Clearance Circle | 21.5 ft (6.6 m) |
| Speed | 14.5 mph ± 0.5 mph (23.3 kph ± 0.8 kph) |
| Steering | Self-Compensating Rack & Pinion |
| Suspension | Leaf Springs w/ Hydraulic Shock Absorbers |
| Service Brake | Rear Wheel Mechanical, Self-Adjusting Drum |
| Parking Brake | Self-Compensating, Single-Point Engagement |
| Tires | 18 x 8.5 – 8 (6 Ply-Rated) |
